Titus 2C
An energy-efficient linear LED high bay suitable for logistic applications
- An easy-to-use linear highbay for general logistic applications with optimized initial investment
- Extruded aluminium body serves as an effective heat sink for excellent thermal management
- Built-in linear LED lens to provide medium beam distribution
Materials and Finish
Body: Extruded aluminium with silver powder coating
Optics: PC lens
End cap: PC
安装与固定
Suspend mounted: Make 2 holes with size M6 x 30mm in the ceiling, put in plastic anchor and fix the suspension wire holder firmly, pass the suspension wire through the holder and set the required installation height for the luminaire, finally, connect the 220VAC Mains power to the LED transformer.
Specification
To specify state:
Suspended linear type LED highbay, extruded aluminium body with silver powder coating and linear PC lens offering comfortable lighting effect. External high efficiency LED transformer optimised for energy saving in logistic and industry application. Colour rendering Ra > 80 colour temperature 5000K. long lifetime performance Ta25°C up to 50,000hrs for luminous flux at L70 of initial value, mains voltage: 220-240VAC / 50-60Hz; CCC certified.
As Thorn TITUS 2C LED
▼ Titus 2C
| Description | Type | Wt (kg) | SAP Code | ||||||
|---|---|---|---|---|---|---|---|---|---|
| TITUS 2C LED13000-850 L1200 HF SA | LED | 3.53 | 22665791 | ||||||
| TITUS 2C LED15000-850 L1200 HF | LED | 3.23 | 22665790 |
