Clan C LED为阿伦达尔体育公园提供室外照明
挪威Sør Amfi Arendal（阿伦达尔体育公园）于2012年8月完工。该场地由阿伦达尔市、东阿格德尔郡和体育协会合力承办，内部设施由室内网球场、运动馆和健身房以及行政楼、VIP房间和健身中心组成。外部设施包括网球和排球场、停车场以及景观区域。
Thorn索恩照明与电气承包商Agder El.Installasjon AS合作，提供主要用于人流量较多的公共区域的室内和室外照明。承包商和建筑设计顾问在灯具的选择中发挥着主要作用。
在所选的七种灯具中，Clan C LED用于停车场，通道以及排球场、溜冰场和网球场。Clan C LED拥有低调现代的特质，其适应性广泛的一体化设计包括三个支架、两个光学器件和15个光源。Clan C LED还提供街道或非对称配光，并且包含调光和控制选项，以优化能耗。
用于为Sør Amfi Arendal提供照明的先进LED灯具（39W，58W）符合EN13201标准，预期寿命达50000小时（@L80, Ta 25°C）。相较于陈旧的安装方式，集成调光功能可在不影响照明水平或光线质量的情况下，使得能耗的最大降幅达到50%。
Clan C LED 根据需要提供合适的照明，防止溢散光的出现并减少灯具的用量。与传统的光源相比，单个LED周围的精准光学设计显示出更为出色的间距和统一性。
Sør Amfi Arendal的安装还配备识别能见度安全（IVS）系统，通过专用的双非对称光学器件提升行人的安全程度。额外信号的使用便于驾驶员在较远距离以外看到人行道以及路边的行人，行人则可以清晰地看到人行道表面、障碍物以及其他行人。IVS系统的安装高度相同（4至7米之间），使用一致的机身设计，确保计划的整体一致性。
来自Agder El. Installasjon AS的Paal Dokkedal表示：“我们对Thorn 索恩照明提供的所有室内和室外灯具都十分满意。在减少能耗，为Sør Amfi Arendal提供优质照明的同时，它们与这里的现代环境相辅相成。”
资料
- 该项目选择了以下灯具：Base LED、Cruz LED、Glacier II LED、EquaLine LED、D-CO LED、Clan LED和 Band 2
- 针对室内照明控制，Thorn索恩照明简单的独立解决方案得到采纳，各个区域可接受单独控制。所用灯具包括SwitchLite、SensaDigital和SensaDAY。
- 该照明方案由Thorn与电气承包商AgderEl.installasjon共同完成。
